China 6 Pot Brake Kit manufacturer

20in Wheel Drilled Cast Iron Brake Disc 390x36mm Suits CP8520 Caliper

Product Details:
Place of Origin: China
Brand Name: Jekit
Model Number: JK390*36
Payment & Shipping Terms:
Minimum Order Quantity: 1pair
Price: Factory Price
Packaging Details: Box Size 45*45*25cm
Delivery Time: 5-7 days
Payment Terms: Western Union,Paypal, T/T
Supply Ability: 600 sets Per Month

Detail Information

Item Name: Slot Disc Brake Disc Design: Slot
Disc Size: 390*36mm Fit Wheel: Rim 20 Inch
Disc Material: Grey Cast Iron HT250 Disc Hole: 24 Holes
Fit Caliper: CP8520 Center Cap Design: Floating
High Light:

Drilled Cast Iron Brake Disc


20in Wheel Iron Brake Disc


CP8520 Caliper Drilled Brake Rotor

Product Description

Jekit Car Brake Disk 390x36mm Drilled Brake Disc For Audi RS6 C7


The Disc Size We have




If only need disc with center cap. Please tell disc diameter/Thickess/Height/Center bell thickness/Disc area

If only need disc. Please offer disc diameter/thickness/Disc data


About Brake Disc

The design of scribing / punching is to take away the brake dust (sometimes soil and rain) faster during braking, and reduce the "air cavity phenomenon" at the moment of contact between the brake pad and the brake disc at the initial stage of braking, so as to improve the braking efficiency, sensitivity and reliability. Different scribing / punching patterns will have different effects / effects on their friction characteristics. The differences are: the whole braking friction performance, the invasiveness to the brake pad and brake disc itself, the characteristics when releasing the brake pedal (i.e. the caliper piston stops applying pressure to the brake pad / brake disc), and the foot feeling. Therefore, after meeting the physical size requirements of the vehicle / caliper, the choice of its grain is actually diverse, which is mainly matched according to the needs of the driver / vehicle.


The ventilation groove design, grain / perforation design and positioning of the brake disc are precision designed, using qualified raw materials, rigorous processing to ensure strength, considering better heat dissipation and heat dispersion stability, so as to improve braking efficiency and durability


If there is only slight rust, it can be removed by continuous braking during driving. Because the disc brake is braked by the friction between the brake caliper and the brake pad, the rust can be removed by repeated braking. Of course, the premise is to be in a safe road section.

The above "polishing" method can be adopted for slight rust, but it is not applicable for serious rust. Because the rust is too stubborn, the brake pedal and steering wheel will shake obviously during braking, which can not be "polished", but also accelerate the wear of brake pads. Therefore, in this case, it is best to find professional maintenance personnel to remove the brake disc for grinding and clean the rust.

However, if the rust is particularly serious, even a professional repair shop can't do anything, so we can only change a brake disc. Therefore, if the vehicle is often placed, the owner had better maintain the brake disc every two months to avoid serious corrosion of the brake disc, and it is also convenient to drive on the road at any time.


When to replace the brake disc depends on many factors. Generally speaking, the service life of the brake disc is much longer. As long as there is no abnormal noise and jitter when braking, it is not a dream to use 100000 km. There are even and smooth marks on the surface of the normal brake disc. Sometimes there is a large area of rust on the brake disc after rain, which is also a normal phenomenon. But if the brake is abnormal and a new brake pad is not solved, you have to check the brake disc. Little wear and tear, can be "repaired and renovated". This is a fine technical work. If it is not repaired well, it can only aggravate the jitter. If the wear is too large, it has to "change the disc".


Item Name Floating Brake Disc with center bell
Disc Size 390*36mm
Disc data Locating Edge 208.2mm
Disc Material Grey Cast Iron HT250
Disc type Slot Disc
For Wheel size Rim 20 inch
Fit Caliper CP8520/AMG6/CP9560


20in Wheel Drilled Cast Iron Brake Disc 390x36mm Suits CP8520 Caliper 0


 20in Wheel Drilled Cast Iron Brake Disc 390x36mm Suits CP8520 Caliper 120in Wheel Drilled Cast Iron Brake Disc 390x36mm Suits CP8520 Caliper 2
