China 6 Pot Brake Kit manufacturer

HP1000 JK5200 Caliper Auto Brake Pad Semi Metallic Friction Surface 50mm

Product Details:
Place of Origin: China
Brand Name: Jekit
Model Number: JK5200DHP1000
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Factory price
Packaging Details: 20*20*20cm
Delivery Time: 5-7 days
Payment Terms: Western Union/Paypal
Supply Ability: 600 sets Every Month

Detail Information

Item Name: JK5200 Brake Pad Friction Surface: 50mm
Warranty: 12 Months Applicable Rotor Temperaure: 0-650°C
For Caliper: 5200 Caliper Friction Coefficient: 0.40-0.45μ
Materials: Semi-metallic Material
High Light:

JK5200 Caliper Auto Brake Pad


HP1000 Auto Brake Pad


50mm Friction Surface Auto Brake Pad

Product Description

HP1000 JK5200 Caliper Pads Semi Metallic Friction Surface 50mm
Brake pad:

Material: Semi-metallic material
Heat-resistant: 0-650°C
Friction Coefficient: 0.40-0.45μ
Friction Surface:50mm

When do you need to change the brake pads?
The replacement time period of brake pads and brake discs is not fixed, which depends on the driving conditions of the vehicle, the frequency and strength of the driver's brake pedal. Generally, the replacement mileage of conventional brake pads is about 25,000-30,000 kilometers per driving.
01. Brake pad thickness is too low
02. Instrument indicator light alarm
03. Wear indicator touches brake disc
04. Brake pad is covered with oil
05. Generate severe wear
06. Abnormal wear of brake pad



The reason why the brakes squeal abnormally


The reason for abnormal brake sound 1: brake pad metal hard point. There will be some small metal particles inside the brake pad, lightly stepping on the brake will make a sharp and harsh sound, this problem can be slammed on the brake or the brake pad removed and re-polished, can also be replaced with a better brake pad.


The reason for abnormal brake sound 2: brake pad assembly problems. This situation please try to reinstall the brake pad, to the brake pad and brake caliper joint smear butter or special lubricating oil can be solved. It is also possible that the brake pads are installed backwards and can be reassembled. Especially in the roadside stall replacement brake pad owners, should pay more attention to this point.


The reason for abnormal brake sound 3: the brake sub-pump does not return to position . It is mostly the problem of the brake tube. Rust or dirty lubricating oil in the brake tube will lead to poor return position. Clean the brake tube, polish it with fine sandpaper and apply new lubricating oil. There may also be a problem with the brake sub-pump, which needs to be replaced, but this kind of failure is less.


The reason for abnormal brake sound 4: new car running in. A new car or just changed brake disc, there will be a run-in period, in the run-in period rabbit will have some abnormal sound, generally run hundreds of kilometers later, will be eliminated.


The reason for abnormal brake sound 5: the ABS system starts normally. When the ABS brakes sharply, the brake pedal will have a continuous sound of "thrumming", and sometimes there will be a phenomenon of bouncing feet. This indicates that the ABS system starts and it is a normal sound.


The reason for abnormal brake sound 6: brake pad wear is serious, began to alarm. Brake pads generally have an alarm sheet, when the brake pad wear to the limit when the alarm sheet and brake disc friction, give birth to sharp metal friction sound, at this time must be replaced in time, so as not to scratch the brake disc, brake failure.


New brake pad run-in instructions
Note: After the replacement of brake brake pad, if the brake feels soft, Be sure to use the brakes a few times to clear the gap between the brake pads and the disc.Need to run 800-1200 km to achieve better braking effect..Try to run in where the road is good and there are fewer cars,and repeat at least 10 braking cycles.(As shown above)


product Introduction


Name JK5200 Brake pads ( H1000 )
Material Ceramic carbide metal material
Applicable rotor temperaure 0-650°C
Friction coefficient 0.40-0.45μ
Weight 3kg

HP1000 JK5200 Caliper Auto Brake Pad Semi Metallic Friction Surface 50mm 0

HP1000 JK5200 Caliper Auto Brake Pad Semi Metallic Friction Surface 50mm 1
