China 6 Pot Brake Kit manufacturer

16in Wheel Red Tesla Brake Pads For Rear Double Caliper

Product Details:
Place of Origin: china
Brand Name: Jekit
Model Number: Tesla Motor
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: factory direct price
Packaging Details: 30*30*20cm
Delivery Time: 5-8 work day
Payment Terms: T/T, Western Union,paypal
Supply Ability: 99

Detail Information

Product Name: Tesla Motor Position: 1 Pot
Fit Wheel Size: 16/17/18/19/20/21/22 Inch Calipers Color: Red
Caliper Material: Aluminum Pads Material: Carbon Metal
Pads Heat Resistance: 600°C Application: Auto Part
High Light:

Red Tesla Brake Pads


16in Wheel Tesla Brake Pads


16in Wheel Red Brake Pads

Product Description

Jekit Car Brake Red Tesla Motor Pads For Rear Double Caliper



Product Form


Item name Electronic handbrake
Color Red
Fit for Rear double caliper
Quality 100% Tested
Full set included 1 pair motor /1 pair pads /1 set bolts



Product Description
Electronic handbrake is a technology that realizes parking brake by electronic control method. Its working principle is the same as that of a mechanical handbrake. The parking brake is controlled by the friction generated by the brake disc and the brake pads, but the control method is changed from the previous mechanical handbrake lever to an electronic button.
The electronic handbrake is also the electronic parking brake system. Electronic Park Brake (EPB) refers to a technology that integrates the functions of temporary braking during driving and long-term braking after parking, and realizes parking braking by electronic control.
The electronic handbrake extends from the basic parking function to the automatic parking function AUTO HOLD. The application of AUTO HOLD automatic parking function technology makes the driver not need to brake for a long time when the vehicle is stopped. When the automatic electronic parking brake is activated, unnecessary coasting of the vehicle can be avoided.

Compared with the traditional manual mechanical parking brake system, the electronic parking brake system has the following advantages:
(1) The parking brake handle is cancelled in the compartment, which provides more room for the design of the interior design of the vehicle.
(2) The parking brake uses a button to replace the driver's forceful pulling of the parking brake handle, which is simple and labor-saving, and reduces the operating intensity of the driver, especially the female driver.
(3) With the continuous development of automotive electronic parking control technology, the system can not only realize basic functions such as static parking, static release (closed), and automatic release (closed), but also adds automatic parking and dynamic parking, etc. Accessibility. For example, the AUTO HOLD automatic parking button installed on the Volkswagen car series can complete the above-mentioned functions. Because it incorporates the dynamic stability control system into the electronic parking brake system, it makes driving safer and more convenient.


The working principle of the electronic parking system is the same as the manual mechanical parking brake system. The parking is realized by friction clamping between the brake shoe and the brake hub or the friction plate and the brake disc, but the control method is electronic Buttons and motor actions replace the original manual operation and mechanical linkage, so the system is called an electronically controlled mechanical parking brake system.
At present, there are two main forms of electronic parking brake technology used in automobiles, one is the cable-type electronic parking brake system, and the other is the caliper integrated electronic parking brake system. Since the cable-type electronic parking brake system retains the cable of the traditional mechanical parking brake system, it is only a transitional product used in the early stage, and it is less used in automobiles. At present, the caliper integrated type is the most widely used in automobiles. Electronic parking brake system. The system uses electronic buttons and motor components to replace the traditional parking brake handles, mechanical levers and cables and other controls. The electric motor assembly is integrated into the left and right rear brake calipers, and the electronic control unit (ECU) and the electric motor assembly are directly connected through the electrical wiring harness. When parking, when the driver operates the electronic button of the electronic parking brake system, the electronic control unit will control the actions of the motors integrated in the left and right brake calipers, and drive the brake caliper pistons to move to generate mechanical clamping force to complete the parking .


reference picture


16in Wheel Red Tesla Brake Pads For Rear Double Caliper 016in Wheel Red Tesla Brake Pads For Rear Double Caliper 116in Wheel Red Tesla Brake Pads For Rear Double Caliper 2
